50
07610-004-37-13-R
ITEM QTY DESCRIPTION PART NUMBER
1 1 Pump Casing SS, 60 Hz 05700-002-85-00
2 1 Impeller, 60 Hz 05700-002-81-86
3 1 Mechanical Seal, 60 Hz 05330-002-34-22
4
1 Seal Plate, 60 Hz 05700-002-81-87
1 Case O-ring, 60 Hz 05330-002-81-83
1 Drain Plug (Not Shown) 04730-002-81-89
5 1 Motor Only, HT/LT/LT-H 06105-004-32-04
6 1 Shim Kit 05700-002-82-58
7 1 Case Capscrew 05305-356-04-00
8
2 Bolt, 3/8" 05305-276-03-00
2 Lock washer, 3/8" 05311-276-01-00
2 Nut Hex, 3/8-16 05310-276-01-00
9 1 Mounting Bracket 05700-003-31-58
Complete Pump & Motor Assembly, DishStar HT/LT/LT-H
06105-004-35-22
PARTS
MOTOR & PUMP
