52
07610-004-37-13-R
Complete Rinse Arm Assembly
2 per Unit on HT
0 per Unit on LT/LT-H
05700-031-39-21
Rinse Arm Bearing Kit
06401-004-57-50
ITEM QTY DESCRIPTION PART NUMBER
1 1 Retaining Ring 05340-112-01-11
2 1 O-ring (included in item #3) 05330-002-60-69
3 1 Bearing Assembly, Rinse Arm 05700-004-54-71
4 1 Rinse Arm 05700-031-38-30
5 2 End-cap, Rinse Arm 04730-111-60-41
4
5
PARTS
RINSE ARMS & WASH ARMS
1
3
2
