07610-004-37-13-R
57
PARTS
LT/LT-H DOOR
ITEM QTY DESCRIPTION PART NUMBER
1 1 Outer Door Weldment 05700-004-36-55
2 2 Screw, 10-32 x 1/4" 05305-173-01-00
3 2 Bolt, 1/4-20 x 3/8" Hex 05305-274-20-00
4 2 Nut, Lock 10-32 Hex with Nylon Insert 05310-373-02-00
5 2 Washer, SS 1/4-20 ID 05311-174-01-00
6 1 Bracket, Door Magnet 05700-004-52-68
7 1 Door Handle 05700-003-26-62
8 2 Stop, Door Hinge 05700-003-32-55
9 1 Hinge, Left 05700-003-32-71
10 1 Hinge, Right 05700-003-32-72
11 1 Inner Door 05700-003-33-21
12 14 Screw, 10-32 x 1/2" Pan Phillips Head 05305-011-44-52
13 1 Baffle, Door 05700-003-33-38
14 2 Hinge Spacer 05700-003-33-42
15 1 Switch Assembly 05700-003-34-80
16 2 Retaining Plate 05700-011-44-37
17 1 Magnet, Door 05930-002-88-42
18 1 Channel, Door Seal 05700-003-55-49
19 6 Screw, 1/4-20 x 1 1/2" Hex 05305-274-23-00
20 1 Gasket, Door L 05330-004-36-05
21 1 Gasket Clamp 05700-004-36-56
22 6 Pop Rivet, 1/8" x 3/8" 05320-003-06-98
