Jackson DishStar LT - Page 66

07610-004-37-13-R
59
MISCELLANEOUS DOOR COMPONENTS
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Switch Mounting Plate Assembly 05700-003-33-54
2 1 Door Spring 05700-003-32-85
3 1 Cover, Left Hinge Weldment 05700-004-36-80
4 1 Cover, Right Hinge Weldment 05700-004-36-81
Hinge Components secured with Locknut, 1/4-20 Hex with
Nylon Insert
05310-374-01-00
5 2 O-ring 05330-003-32-34
6 1 Latch Spring 05700-003-32-32
7 2 Latch Nut 05700-003-32-33
8
2 Hardware: Locknut, 6-32 Hex with Nylon Insert 05310-373-03-00
2 Screw, 6-32 x 1/4” Flat Head 05305-171-01-00
9 1 Door Switch 05930-003-31-44
10
1 Door Switch Bracket 05700-003-31-43
1 Door Switch & Bracket Assembly 05700-003-32-21
11 1 Complete Switch Mount Assembly (LT/LT-H) 06401-004-47-76
12 1 Complete Switch Mount Assembly (HT) 05700-005-07-45
