GB-18
JACOBSEN 405 Series: CH
MAINTENANCE AND PARTS MANUAL
ADJUSTMENTS
6.5 STANDARD FOOT BRAKE & BRAKE
BANDS
Adjust so that both brakes lock evenly when the
parking brake foot pedal is depressed. Loosen nuts
A and turn nuts B on the two cables (Fig.20). Also,
adjust nuts A (Fig.21) for each wheel so that neither
brake band drags when the parking brake is
disengaged.
Fig.20
Fig.21
6 ADJUTMENTS
