Jacobsen Fairway 405 User Manual

GB-21
JACOBSEN 405 Series: CH
MAINTENANCE AND PARTS MANUAL
KEY TO HYDRAULIC CIRCUIT
1 CUTTING UNIT MOTOR
2 LIFT CYLINDER
3 RETURN MANIFOLD
4 PRESSURE MANIFOLD
5 LIFT VALVE
6 BACK PRESSURE VALVE
7 LEFT FRONT MOTOR
8 LEFT REAR MOTOR
9 RIGHT REAR MOTOR
10 RIGHT FRONT MOTOR
11 STEERING GEAR
12 STEERING CYLINDER
13 STEERING WHEEL
14 TWO SECTION PUMP
15 DECK VALVE
16 RESERVOIR
17 FILTER HEAD
18 INLET MANIFOLD
19 OIL COOLER
20 M46 SAUER TRANSMISSION PUMP
21 ENGINE
22 F/N/R VALVE
23 TRANSMISSION VALVE
24 ROTARY FLOW DIVIDER
8.1 HYDRAULIC CIRCUIT
8 SCHEMATICS
