Jacobsen Fairway 405 User Manual

GB-23
JACOBSEN 405 Series: CH
MAINTENANCE AND PARTS MANUAL
8.2 ELECTRICAL CIRCUIT MAIN
8 SCHEMATICS
KEY TO WIRING DIAGRAM
1 ALTERNATOR
2 ALTERNATOR
3 WATER TEMP SENDER
4 OIL PRESSURE SWITCH
5 STARTER
6 12V BATTERY
10 70 AMP RELAY
11 EARTH
12 GLOW PLUGS
13 RUN SOLENOID
15 4WD SOLENOID
17 FUEL PUMP
18 CONNECTOR
23 OIL TEMP SWITCH
25 BACKLAP SWITCH
26 FUEL LEVEL SENDER
27 CUTTER RELAY
28 STARTER RELAY
29 SPLIT TO INSTRUMENT PANEL #3
31 KEY SWITCH
32 SPLIT TO INSTUMENT PANEL #1
33 SPLIT TO INSTRUMENT PANEL # 2
40 HOUR METER
41 LAMP RELAY
42 REEL SWITCH
43 NEUTRAL SWITCH
44 SEAT SWITCH
45 40 AMP CIRCUIT BREAKER
46 SEAT DELAY RELAY
47 FUSES
48 SPLIT TO OIL LEAK SENSOR
50 FOOT SWITCH
51 RH BRIDGE
52 CENTRE BRIDGE
53 LH BRIDGE
54 LH RELAY
55 CENTRE RELAY
56 RH RELAY
57 LH LIFT ARM SWITCH
58 CENTRE SOLENOID
59 LH SOLENOID
60 FLOW DIVIDER
61 RH SOLENOID
62 RH LIFT ARM SWITCH
63 SPLIT TO CAB WIRING
64 SPLIT TO JOYSTICK
65 MODULE SPLIT A
66 MODULE SPLIT B
67 LOWER LH SOLENOID
68 LOWER RH SOLENOID
69 LOWER CENTRE SOLENOID
70 RAISE RH SOLENOID
71 RAISE LH SOLENOID
72 RAISE CENTRE SOLENOID
73 MAST/FLOW SOLENOID
74 TRANSPORT SWITCH
CABLE COLOUR CODE
R Red
G Green
O Orange
S Grey
B Black
W White
K Pink
P Violet
Y Yellow
U Blue
N Brown
LG Light Green
E.G. R/W = Red/White
