GB-7
JACOBSEN 405 Series: CH
MAINTENANCE AND PARTS MANUAL
4 SPECIFICATIONS
4.1 ENGINE SPECIFICATION
TYPE: Kubota 34.7KW (46.5HP) @
3000 RPM, 4 cylinder (in line)
Turbo charged Diesel engine, 4
stroke, water cooled, 1498cc
(91.44 cu.in) with 12V electric
start.
Model: V1505-TE
Maximum Speed: 3000 ± 50 RPM (No load)
Idle Speed: 1500 RPM
Oil Sump Capacity:6.4 litres (11.26 Imp.pints)
Fuel: No. 2-D Diesel fuel (ASTM D975)
4.2 MACHINE SPECIFICATION
Frame construction:Heavy duty formed steel chassis
with box section frame rails.
Cutting unit drive: Fixed displacement hydraulic
motors directly coupled to
cutting unit.
Transmission: Full time 4-wheel drive. Direct
coupled variable displacement
pump to direct coupled 29 cu in
front, 21 cu in rear wheel motors.
Speeds:
Cutting: 0 - 12km/h (0 - 7.5 mph)
FORWARD
Transport: 0 - 14km/h (0 - 8.7mph)
FORWARD
Reverse: 0 - 6.4km/h (0 -4 mph)
Steering: Hydrostatic power steering, with
adjustable tilt steering wheel.
Tyres:
Front - Front - 26.5 x 14.00 - 12 4 ply
rating turf
Rear - Rear - 20 x 10.00 - 8 4 ply rating
turf
Pressures: All tyres
14p.s.i. (1 kg/cm
2
)
Ground pressure: 14p.s.i. (1 kg/cm
2
)
Brakes: Hydrostatic braking with
mechanical type band parking
brakes, 260mm x 45mm
(10.25in x 1.75in) on front
wheels.
Fuel Tank
Capacity: 45.4 litres
Hydraulic Tank
Capacity: 37.8 litres
Battery: Exide 093 (SAE 500)
4.3 DIMENSIONS
Width of cut: 4.0 metres (158in)
Overall width: 4.31 metres(170in)
Overall width: 2.52 metres (99.2in)
(transport)
Overall height: 1.6 metres (63in)
Overall length: 2.75metres (113.4in)
Overall weight of
machine: 1860kg (4100lb)
4.4 VIBRATION LEVEL
The machine was tested for whole body and hand/
arm vibration levels. The operator was seated in the
normal operating postion with both hands on the
steering mechanism. The engine was running and
the cutting device was rotating with the machine
stationary.
Standard ISO 5349: 1986 Mechanical vibration.
Guidelines for the measurement and the
assessment of human exposure to hand-
transmitted vibration.
Standard ISO 2631-1: 1985 Evaluation of human
exposure to whole body vibration -- Part 1:
General requirements.
OBRUT504
HCseireS
noitareleccAmrA/dnaH
level
HRroHLxaM
s/msnoitareleccA
2
qeAXqeAYqeAZ
604.0523.0192.0
eulaVtnanimoD604.0
4.5 SLOPES
DO NOT USE ON SLOPES GREATER THAN 15°
The slope 15° was calculated using static stability
measurements according to the requirements of
EN 836.
OBRUT504
HCseireS
ydoBelohW
noitareleccA
level
noitacoLroolF
s/msnoitareleccA
2
noitacoLtaeS
s/msnoitareleccA
2
xyzxyz
naeM10.0510.01640.010.0910.0520.0
