© Copyright 2010, Jacobsen, A Textron Company. “All rights
reserved, including the right to reproduce this material or portions
thereof in any form.”
This manual contains adjustment, maintenance,
troubleshooting instructions, and parts list for your new
Jacobsen machine. This manual should be stored with
the equipment for reference during operation.
Before you operate your machine, you and each operator
you employ should read the manual carefully in its
entirety. By following the safety, operating, and
maintenance instructions, you will prolong the life of your
equipment and maintain its maximum efficiency.
If additional information is needed, contact your
Jacobsen Dealer.
The serial plate is located on the right frame rail.
Jacobsen recommends you record these numbers below
for easy reference.
®
P.O. BOX 7708,
CHARLOTTE,
NC 28241, USA
A T extron Compa n y
kg kg kg kW
Jacobsen.com
1-800-848-1636 (US)
PRODUCT OF U.S.A.
CHARLOTTE, NC PRODUCT OF U.S.A.
®
A Textron Company
2
Proposition 65 Warning
This product contains or emits
chemicals known to State of California
to cause cancer and birth defects or
other reproductive harm.
FOREWORD
Suggested Stocking Guide
To Keep your Equipment fully operational and productive, Jacobsen suggests you maintain a stock of the more
commonly used maintenance items. We have included part numbers for additional support materials and training aids.
To order any of the following material:
1. Write your full name and complete address on your
order form.
2. Explain where and how to make shipment:
❑ UPS ❑ Regular Mail
❑ Overnight ❑ 2nd Day
3. Order by the quantity desired, the part number, and
the description of the part.
4. Send or bring the order to your authorized Jacobsen
Dealer.
Litho In U.S.A. 3-2010
Service Parts
Service Support Material
Qty. Part No. Description Qty. Part No. Description
4113986 Engine Oil Filter 555771 Hydraulic Return Oil Filter
549633 Engine Air Filter 2811255 Hydraulic Charge Oil FIlter
557619 Engine Fuel Filter
Qty. Part No. Description
4192120 Safety & Operation Manual
4192121 Parts & Maintenance
4192126 Kubota Engine Parts Manual
4219160 Operator Training Video (DVD)
Qty. Description
Service Manual
