73
> Change from previous revision
7
9
5
12
6
7
1
10
8
11
7
4
3
2
R-311
Item Part No. Qty. Description Serial Numbers/Notes
1
1001226 1 Muffler
2 1001251 1 Exhaust Pipe
3 553020 1 Gasket, Exhaust Included with Engine
4 594331 4 Bolt and Lockwasher Set Included with Engine
5 1000050 2 Muffler Bracket
6 400188 4 Screw, 5/16-18 x 1” Hex Head
7 452006 12 Flat Washer, 5/16
8 3000098 4 Mount, Isolation
9 444718 4 Locknut, 5/16-18 Center
10 443106 4 Nut, 5/16-18 Hex
11 446136 4 Lockwasher, 5/16 Heavy
12 162236 1 Clamp, 2-1/8” Muffler
22.1 Muffler
