Jacobsen R-311 Parts & Maintenance Manual

35
> Change from previous revision
R-311
Item Part No. Qty. Description Serial Numbers/Notes
1
4199160 1 Decal, R-311 Weight Located on right frame rail
2 4117468 1 Decal, 105 dB Noise Located on right frame rail
3 4194260 2 Decal, ROPS Deployment Located on ROPS folding section
4 REF 1 Serial Plate Located on right frame rail
5 4181865 1 Decal, Warning
6 366608 2 Decal, Wing Transport Lock Cable
7 4192000 1 Decal, Weight Transfer
8 4187682 2 Decal, R-311
9 4202200 1 Decal, Left Side Stripe
10 4202201 1 Decal, RIght Side Stripe
11 4181863 1 Decal, See Manual for Maintenance Located on Charge Filter Bracket
12 4181863 1 Decal, See Manual for Maintenance Located on Hydraulic Tank
13 4182386 1 Emblem, Jacobsen
14 4181861 1 Decal, Start Assist Located on Air Cleaner
15 4181862 1 Decal, Radiator Warning Located on Radiator
16 3008521 1 Decal, Accelerator
17 3008004 1 Decal, Brake
18 4170760 1 Decal, Instrument Panel
19 366866 1 Decal, Symbol Use Horn Portion of Decal Only
20 3002565 1 Decal, Relay Identification Located on inside of relay cover
21 363995 1 Decal, Antifreeze Located on Radiator
22 4199140 1 Decal, Heat Warning
23 4164381 1 Decal, Danger Located on Fan Shroud
24 4205183 1 Decal, Towing Warning
