Jadever JCL Series Service Manual

RS232+RTC+Relay
RS232+RTC+Relay
JADEVER SCALE CO., LTD
LED Light Tower
+
EZ
→
2008-06-28
14:47:25
3-4 Two options
+
→
PC
G.W.:+ 4.000kg
U.W.: 20.000g/pcs
Total: 200pcs
Scale to PC and light tower
Wire connection
Note: The hollow dots represent the
male connectors and the black dots
are for female connectors.
Pictures
9 JCL Service Manual
