JADEVER SCALE CO., LTD
9. Put the scale upside down, and 10. Install the stainless steel weighing
tighten the 4 fixing screws. pan properly.
6-6 LCD replacement
1. Cut off the defective LCD. 2. Remove the LCD which is been cut off from
the main board.
3. Remove the residual tin from main 4.Install a new LCD in level.
board.
5. Use tin to weld the LCD, with care. 6. Replacement is completed.
27 JCL Service Manual
