Jadever JCL Series Service Manual

1.Assembly Drawing
1.1 Explosive view
1-2 List of parts
No. Part Name
1 Xm JCL front panel
2 Xm Keypad
3 Xm Leveler
4 Xm Transformer
5 Xm Switch
6 Xm Two-stage switch
7 Xm JCL main board
8 Xm Bottom cover
9 Xm Lower support
Quantity
1
1
1
1
1
1
1
1
1
Part No.
JCL-1
JCL-2
JCL-3
JPL-4
JCL-5
JPL-6
JCL-7
JCL-8
JCL-9
Material No.
20-1925-0000
21-0506-0000
02-0108-0003xm(14mm)
61-0003-0400
60-0000-0000xm
60-0503-0001xm
80-0124-0000
02-0000-6020
10-0425-0100
