JADEVER SCALE CO., LTD
After finished grinding the scale, please install the upper cover, turn the scale upside down,
then tighten 4 fixing screws, and then cover the stainless weighing pan.
12. Switch on the scale, conduct calibration then check weighing functions.
Model
JCL-1.5K
JCL-3K
JCL-6K
JCL-7.5K
JCL-15K
JCL-30K
LC Max. capacity
(ZEMIC load cell)
3kg
5kg
10kg
10Kg
20Kg
40kg
LC Max. capacity
(MAVIN load cell)
3kg
4.5kg
7.5Kg
10Kg
20Kg
45Kg
6-3 Rechargeable Battery Replacement
1.Remove the stainless weighing pan. 2. Put the scale upside down, Loosen
and remove the screw on the battery cover.
3.Remove the battery cover. 4. Disconnect the wire connection then remove
the rechargeable battery.
5.Prepare for a new rechargeable 6. Put the rechargeable battery in the
battery and make sure the red end chamber with literal side upward and the
connected to red wired and black end wire to the right side.
connected to black wire.
24 JCL Service Manual
