Jandy HI-E2 User Manual

Page 3
ENGLISH
Jandy
®
Pro Series, Hi-E2
®
and Hi-E2R Gas-Fired Heater
|
Installation & Operation Manual
Table of Contents
Section 1. General Information ....................... 4
1.1 Introduction ......................................................... 4
1.2 Description ......................................................... 4
1.3 Warranty ............................................................. 4
Section 2. Installation Instructions ................. 4
2.1 General Requirements ....................................... 4
2.2 Heater Assembly and Preparation ...................... 5
2.3 Heater Location .................................................. 5
2.4 Installation Clearances ....................................... 5
2.5 Outdoor Installation ............................................ 5
2.6 Outdoor Shelter Installation (Canada) ................ 6
2.7 Indoor Installation ............................................... 6
2.7.1 Preparation of Heater For Indoor
Installation .................................................... 6
2.7.2 Combustion Air Requirements for
One-Pipe Installation .................................... 7
2.7.3 Two-Pipe Installation (Direct Vent) ............... 7
2.8 Condensate Disposal ....................................... 10
2.9 Gas Supply and Piping ......................................11
2.9.1 Special Precautions for LP Gas ................. 12
2.10 Electric Wiring .................................................. 12
2.10.1. Electrical Power .......................................... 12
2.10.2 Bonding ...................................................... 13
2.10.3 Auxiliary Time Clock Wiring ........................ 14
2.10.4 Remote Operation ...................................... 14
2.11 Water Piping ..................................................... 14
2.11.1 Reversal of Water Connections .................. 14
2.11.2 Pool/Spa Piping Systems ........................... 15
2.11.3 Connections at Heater................................ 16
2.11.4 Pressure Relief Valve and
Temperature Relief Valve ........................... 16
2.11.5 Automatic Chlorinators
(Chemical Feeders) .................................... 16
2.12 Start-up and Adjustment ................................... 17
2.12.1 Normal Operation ....................................... 17
2.12.2 Start-up ....................................................... 17
2.12.3 Condensate ................................................ 17
2.12.4 Gas Pressure ............................................. 18
2.12.5 Adjustment of Water Pressure Switch ....... 18
2.12.6 Water Temperature Rise............................. 19
Section 3. Operating Instructions ................. 19
3.1 Start-Up Procedure .......................................... 20
3.2 Temperature Controls ....................................... 20
3.3 Lighting and Shutdown ..................................... 21
3.3.1 Lighting the Heater ..................................... 21
3.3.2 Shutdown ................................................... 21
3.4 Water Chemistry ............................................... 21
3.4.1 Pools .......................................................... 21
3.4.2 Spas ........................................................... 21
3.5 Spa/Hot Tub Safety Rules ................................ 22
3.6 Swimming Pool Energy Savings Tips ............... 22
3.7 Seasonal Care .................................................. 23
3.7.1 Spring and Fall Operation .......................... 23
3.7.2 Winterizing .................................................. 23
3.8 Periodic Inspection ........................................... 23
3.8.1 Owner Inspection ....................................... 23
3.8.2 Professional Inspection .............................. 24
Section 4. Maintenance and Service ............. 24
4.1 General ............................................................. 25
4.2 Induced-Draft Combustion System .................. 25
4.3 Heater Components and Their Operation ........ 26
4.4 Combustion Air Filter ........................................ 26
4.5 Electrical Trouble Shooting ............................... 27
4.5.1 115V Electrical Power Supply .................... 28
4.5.2 Control Circuit Trouble Shooting ................ 28
4.6 Venturi Combustion Flow System .................... 30
4.6.1 Pressure Measurement Ports..................... 30
4.6.2 Venturi System Checkout ........................... 30
4.6.3 Air Flow Investigation ................................. 32
4.6.4 FuelGasTypeandGasOriceSize .......... 33
4.6.5 High Elevation Operation ........................... 33
4.7 Combustion Condensate .................................. 33
4.8 Major Component Service ................................ 34
Section 5. Capacities and Dimensions ......... 34
5.1 General Information .......................................... 34
Section 6. Replacement Parts ....................... 35
6.1 Ordering Information ........................................ 35
6.2 Parts List .......................................................... 35
6.3 Exploded View .................................................. 37

Jandy HI-E2 Specifications

General

Brand	Jandy
Model	HI-E2
Category	Swimming Pool Heater
Language	English
