ENGLISH
Jandy
®
Pro Series, Hi-E2
®
and Hi-E2R Gas-Fired Heater
|
Installation & Operation Manual
29 Pressure Relief Valve, 75 PSI 350 R0040400
 (requireseldsupplied3/4NPTx3"brassnipple)
Heat Exch. Hardware Kit (Note 1) 350 R0319105
Inlet/Outlet Header Hardware Kit (Note 1) R0319300
Return Header Hardware Kit (Note 1) R0319200
COMBUSTION SYSTEM ASSEMBLY
30 Gas Valve 350 R0200100
30A Step Down Regulator 350 R0337300
31 Anti-Rotation Bracket (not shown) 350 R0348500
32 OriceHolder 350 R0320000
33 GasOrice,NAT 350 R0309305
33 GasOrice,LPG 350 R0309405
34 Combustion Air Filter Assembly 350 R0348200
35 Combustion Air Filter 350 R0308000
36 Venturi Inlet 350 R0320305
37 Venturi O-Ring 350 R0320400
38 Venturi Plenum 350 R0320500
39 Venturi/Tailpipe Gasket 350 R0348300
40 Mixing Chamber/Tail Pipe Assy 350 R0320600
41 Mixing Chamber/Burner Gasket 350 R0348300
42 Burner Assembly 350 R0305905
43 Burner/Comb. Chamber Gasket 350 R0305805
44 Combustion Chamber Assembly 350 R0305105
45 Refractory Tile Set 350 R0305305
46 Sight Glass Assembly 350 R0305400
47 Combustion Chamber Strip Set 350 R0213105
(not shown)
48 Combustion Chamber/Coll. Gasket 350 R0305705
Venturi Hardware Kit (Note 1) 350 R0322200
Mixing Chamber Hardware Kit (Note 1) R0322100
Burner Hardware Kit (Note 1) 350 R0319405
EXHAUST ASSEMBLY
49 Blower/Collector Gasket 350 R0308700
50 Combustion Blower 350 R0308200
51 Blower/Vent Duct Sleeve 350 R0308600
52 Blower/ Vent Duct Clamp 350 R0308800
53 Vent Duct Assembly 350 R0303100
54 Vent Duct/Heater Top Gasket or 350 R0309100
Heater Top/Indoor Vent Collar Gasket
55 Heater Top/Outdoor 350 R0309500
Exhaust Grill Gasket
56 Outdoor Exhaust Grill 350 R0348400
57 Indoor Vent Collar (not shown) 350 R0307900
58 Condensate Trap Assembly 350 R0303300
59 Limestone Gravel 350 R0306200
60 Condensate Trap Cover 350 R0213300
Venturi Hardware Kit (Note 1) 350 R0322200
Mixing Chamber Hardware Kit (Note 1) R0322100
ELECTRICAL COMPONENTS AND CONTROLS
61 Transformer 350 R0061100
62 In-Line Fuse Holder Assembly 350 R0325600
63 Ignition Control 350 R0202900
64 Wire Harness, Ignition Control 350 R0302700
65 Igniter Assembly 350 R0016400
66 Igniter Gasket 350 R0205300
67 Terminal Block 350 R0301900
68 High-Limit Switch Set 350 R0322700
69 High-Limit Switch, 135°F 350 R0302400
70 High-Limit Switch, 150°F 350 R0302300
71 High-Limit Switch Wire Harness 350 R0322600
(not shown)
72 Pres. Switch & Siphon Loop Assy 350 R0322900
73 Pressure Switch, 2 PSI 350 R0013200
74 Pressure Switch Siphon Loop 350 R0307800
75 Temp. Control Assy, Electronic 350 R0011700
76 Temp. Sensor (not shown) 350 R0011800
77 Temp. Sensor Gasket 350 E0116400
78 Temp. Sensor Plastic Sleeve 350 10444900+
79 Temp. Control Knob 350 R0010700
80 Pool/Spa Selector Knob 350 R0099900
81 “Temp-Lok” Disc 350 10583100+
82 Temp. Sensor Retainer Clip 350 10716701
(not shown)
83 Differential Pressure Switch 350 R0302000
84 Differential Pres. Switch Bracket 350 R0302200
85 Exhaust Vent Limit Switch 350 R0309000
86 Burner High Limit Switch 350 R0319700
87 Combustion Blower Wire Harness 350 R0308100
OPTIONAL COMPONENTS
High Temp. Silicone Sealant 350 R0322800
 HeatExchangeBafes 350 R0410100
4" Venting Connector, Hi-E2 350 R0444900
NOTES:
1. All hardware sets contain all pieces necessary for
assembly, including gaskets. Not shown.
2. Gaskets and hardware are included in all kits that
involve the removal of a gasket as part of the procedure
to replace a part.
Key Model ORDER
No. Description No. PART NO:
Key Model ORDER
No. Description No. PART NO:
