Page 25LITE 2 MODEL LG POOL AND SPA HEATER
14.Secure the stack to the clips with the screws
supplied in the kit (see Fig. 40).
15.Figure 41 shows a cross-section of the
finished installation.
SECTION 6.
Parts List for Lite 2 Model LG
Heaters
6A. General Information
To order or purchase parts for the Model LG
Lite 2 pool and spa heaters, contact your nearest
Jandy dealer or distributor. If they cannot supply you
with what you need, contact the techical support
department at Zodiac Pool Systems, Inc., 6000
Condor Drive, Moorpark, California, 93021, Tele-
phone 800.822.7933.
Figure 38. Installation of
the Adapter Plate
Figure 39. Fastening the
Adapter Plate
Figure 40. Fastening the Stack
Figure 41. Finished Installation
