6B. PARTS LIST
PILOT GAS SYSTEM - LLG
1 Pilot, Main Burner Assembly, NAT All 10806401
1 Pilot, Main Burner Assemby, LPG All 10806402
2 Pilot Burner, NAT All 10802401
2 Pilot Burner, LPG All 10802402
3 Pilot Electrode All W0040000
4 Pilot Generator All W0036901
5 Ceramic Insulator Assembly All 10418819
6 Thermocouple All W0036500
7 Burner, Main w/Pilot Bracket All 10457500
8 High Voltage Lead Assembly All E0214200
9 Pilot Tubing All 10820502
10 Piezo Lighter Assembly All R0355900
11 Pilot Condensate Shield All R0323300
MAIN GAS ASSEMBLY
12 Burner Tray Assy, NAT (Note 1) 125-400 10817801-05
12 Burner Tray Assy, LPG (Note 1) 125-400 10818401-05
13 Burner Tray, Shelf Only 125-400 R0317001-05
14 Gas Valve, NAT All V0075300
14 Gas Valve, LPG All V0075500
15 Gas Orifice, NAT (Note 1) All L0032200
15 Gas Orifice, LPG (Note 1) All L0032900
16 Anti-Rotation Bracket All 10818501
17 Mounting Bracket Assembly All 10419200
18 Burner, Main All L0052300
19 Burner Manifold 125 L0052200
19 Burner Manifold 175 L0006300
19 Burner Manifold 250 L0006400
19 Burner Manifold 325 L0006500
19 Burner Manifold 400 L0006600
20 Gas Valve Fitting All 10807800
ELECTRICAL SYSTEM
21 Temperature Control Assembly All 10846602
22 Wire Set (Not Shown) All R0332700
23 Plate Assembly All 10903300
24 On-Off Switch All R0099800
25 Temperature Control Label All H0209800
26 Temperature Contol with Sensor All R0318800
27 Protector Sleeve, Bulb All 10444900
28 “O” Ring, Temperature Control Bulb All E0116400
29 Thermostat Knob, Black All R0010700
30 Stop Plate, “Temp-Lok” All 10583100
31 Temperature Control Gasket All S0070000
32 Bezel All S0069800
33 Stop Plate Screw (Not Shown) All F0033300
34 Temperature Sensor Retainer Bracket All 10447300
35 Retainer Bracket Screw All F0009100
36 Pressure Switch & Siphon Loop Assembly All R0097600
37 Pressure Switch, 2 PSI All R0013200
38 Siphon Loop Assembly All R0057800
37 Pressure Switch, 1 PSI All R0011300
37 Pressure Switch, 1-10 PSI All R0015500
39 High-Limit Switch Set All R0023200
40 High-Limit Switch, 135° F All R0022700
41 High-Limit Switch, 150° F All R0023000
42 High-Limit Switch Retainer Clip All 10418400
43 High-Limit Switch Retainer Boot (Not Shown) All S0098900
44 High-Limit Switch Cover All 10418301
45 High-Limit Switch Wire Harness All 10419300
46 Fusible Link Assembly All R0012200
47 Fusible Link Bracket All 10479901
48 Terminal Block All R0097800
49 Overheat Thermostat Assembly All 10818201
50 Thermostat only All E0155300
51 Capillary Cover and Insulation All R0356000
52 Sensor Cover and Insulation All R0356100
VENT SYSTEM
53 Top Filler Plate 125-400 R0343701-05
54 Top Enclosure 125-400 R0356201-05
55 Rainshield Kit 125-400 R0318301-05
56 Flue Collector Assembly 125 10844201
56 Flue Collector Assembly 175-400 R0316402-05
57 Outdoor Flue terminal 125-400 10561501-05
58 Indoor Draught diverter 125-400 10561406-10
59 Adapter Plate 125-400 10535301-05
60 Clip All 10211000
WATER SYSTEM
61 Inlet/Outlet Header, 2" All R00356300
61 Inlet/Outlet Header, Bronze, 2" All R0016800
62 Return Header All R0058300
62 ReturnHeader, Bronze All R0054600
63 Header Bolt Assembly (Set of 8) All R0057000
64 Bolt for Headers, 2 1/2" All F0046100
65 Washer for Headers All F0011100
66 Nut for Headers All F0003100
67 Header Gasket Assembly (Set of 18) All R0050800
68 Flange & Gasket Assembly (Set of 2) All R0332600
69 Flange, 2" All 10822900
70 Flange Gasket, 2" All S0078000
71 Flange Sleeve, 2" All S0078200
72 Flange Bolt All F0031700
73 Flange Gasket, 1 1/2 - 2" All S0078100
74 Grommet for Drain Plug All R0316300
75 Grommet, Slitted All S0071100
76 Brass Plug, 1/4” All P0026800
77 Brass Plug, 3/4" All P0027000
78 Brass Connector All P0019701
79 Flue Collector Hold Down Clamp All 10726200
80 Hold Down Bracket
81 By-Pass Assembly All R0013100
82 By-Pass Valve Rod All S0079800
83 By-Pass Valve Disc All R0011500
84 Nut (For Rod) All F0048400
85 Hex Bolt, 3/8”-16 x 1” All F0041600
86 By-Pass Valve Control Cap (Iron) All S0069101
86 By-Pass Valve Control Cap (Bronze) All 10557400
87 By-Pass Valve Spring, Purple 125 S0079900
87 By-Pass Valve Spring, White 175 S0061400
87 By-Pass Valve Spring, Red 250 S0061300
87 By-Pass Valve Spring, Blue 325 S0061200
87 By-Pass Valve Spring, Black 400 S0070100
88 By-Pass Valve Gasket All R0011400
89 Heat Exchanger Tube Assembly 125-400 R0018101-05
90 Heat Exchanger Baffle (8 Required) 125-400 10697401-05
91 Baffle Retainer All S0083900
92 Heat Exchanger Support Clip All 10457000
93 Heat Exchanger End Baffle 125-400 R0332301-05
FIREBOX COMPONENTS
94 Combustion Chamber Assembly 125-400 R0316701-05
JACKET COMPONENTS
95 Door with Latch 125-400 R0356501-05
96 Gap Closure, Inlet/Outlet All 10448201
97 Gap Closure, Return All 10448301
98 Button Plug, 1-4/3” All F0035300
99 Button Plug, 7/8” All F0032300
OPTIONAL COMPONENTS
100 Non Combustible Base 125-400 10521701-05
Pressure Relief Valve 3/4" NPT, 75 PSI All R0040400
Touch Up Spray Paint, Pewter & Black All R0335800
