janitza GridVis Collector - Technical Data

110
GridVis
®
Collector www.janitza.de www.janitza.de GridVis
®
Collector
Part number 51.00.400
CPU ARM Cortex
Main memory 1 GB LPDDR2
Measured value memory 60 GByte
Open ports 80, 21, 502, 8082-8084
1)
1)
...Communication port, depending on the setting
in the Collector/GridVis software configuration.
Operating system Linux, Debian
Required
communication ports
Open ports 80, 21, 502, 8082
Communication port, depending on the setting in
the Collector/GridVis software configuration.
Data exchange with the GridVis
software
80, 8082 Communication port for the initial installation.
Send error report to Janitza
Support
80 Is performed via http
Read the measurement devices 80, 21, 502
Synchronize the internal clock
with an NTP server on the
Internet
123/UDP ptbtime1.ptb.de
Display
Type 7” TFT
Luminosity 250 cd/m²
Viewing angle 140 degrees horizontal, 130 degrees vertical
9. Technical data
