janitza GridVis Collector - Table of Contents

4
GridVis
®
Collector www.janitza.de www.janitza.de GridVis
®
Collector
Table of contents
1. General 6
1. 1 Disclaimer 6
1. 2 Copyright notice 6
1. 3 Technical changes 6
1. 4 About this user manual 6
1. 5 Defective device/disposal 7
2. Product description 8
2. 1 Device description 8
2. 2 Firmware 2.0.0 9
2. 2. 1 Compatible devices for readout
via Ethernet 9
2. 2. 2 Compatible devices for read out via
USB/RS-485 converter 9
2. 2. 3 Compatible devices for read out
via an Ethernet gateway
(master device) 9
2. 3 Initial commissioning 9
2. 3. 1 Authentication 11
2. 4 Scope of delivery 12
2. 5 Intended use 14
2. 6 EC Declaration of Conformity 14
2. 7 Performance characteristics 15
2. 8 Identification of the device, rating plate 16
3. Safety 18
3. 1 Display of warning notices and
safety information 18
3. 2 Hazard levels 18
3. 3 Product safety 19
3. 4 Fundamental hazards 19
3. 5 Hazards when handling the device
and the lithium-ion battery 20
3. 6 Qualified personnel 24
3. 7 Warranty in case of damage 24
4. Design of the device 26
4. 1 Location of connections and controls
on the GridVis
®
Collector 26
4. 2 Housing of the GridVis
®
Collector 28
4. 3 Transport case for the GridVis
®
Collector 30
5. Controls and display elements, operating modes 32
5. 1 Power supply 32
5. 2 Ethernet interface 34
5. 3 USB port 34
5. 3. 1 USB/RS-485 converter 35
5. 4 Switching the GridVis
®
Collector on and off 36
5. 5 Operating modes 38
5. 6 Menu structure 40
5. 7 Start screen 42
