6. Commissioning and initial configuration 46
6. 1 Installing GridVis plug-ins in the GridVis
software from the enclosed USB flash drive 46
6. 2 Configuring the GridVis
®
Collector in
the GridVis software 50
6. 3 Assigning measurement devices to the
GridVis
®
Collector in the GridVis software 54
6. 4 Transferring a GridVis software project
to the GridVis
®
Collector 60
6. 5 Integration of RS-485 measurement devices 68
6. 6 Secure data communication 72
6. 7 Windows firewall 76
7. Operation 78
7. 1 Reading out measured values 78
7. 2 Reading out measured values from RS-485
measurement devices 82
7. 3 Synchronizing measured values with the
GridVis software database 84
7. 4 Integrating plug-ins in the GridVis
system service 88
7. 5 Configuration of the automatic start
of the Collector Receiver as of the
GridVis "Service" edition 89
7. 6 Importing new measurement devices
into the GridVis
®
Collector 92
7. 7 Main menu item "Settings" 97
7. 7. 1 LCD brightness 98
7. 7. 2 Time zone 98
7. 7. 3 Language 99
7. 8 Main menu item “Network” 100
7. 8. 1 Ethernet 100
7. 8. 2 WLAN 101
7. 8. 3 Server 103
7. 9 Main menu item “System” 104
7. 9. 1 Function of "Reset" button 104
7. 9. 2 Function of "Update" button 106
7. 9. 3 Function of "Log" button 108
8. Clock/Battery 109
8. 1 Clock 109
8. 2 Battery 109
9. Technical data 110
10. Maintenance and care 114
10. 1 Maintenance 114
10. 2 Care 114
