2. 2 Firmware 2.0.0
As of firmware 2.0.0, the GridVis
®
Collector can also
read RS-485 devices. For this purpose, the Grid-
Vis
®
Collector includes a USB to RS-485 converter
(USB/RS-485 converter tested by Janitza – part no.:
15.06.107).
2. 2. 1 Compatible devices for readout via Ethernet
UMG 604, UMG 605, UMG 508, UMG 509, UMG 511,
UMG512, UMG96RM-E and the respective Pro de-
vices.
2. 2. 2 Compatible devices for read out via USB/RS-
485 converter
UMG 103-CBM, UMG96RM-CBM, UMG 96-PA.
2. 2. 3 Compatible devices for read out via an
Ethernet gateway (master device)
UMG 103-CBM, UMG 96RM-CBM, UMG 96-PA.
In a master/slave topology, you can read out these
devices using the UMG 604, UMG605, UMG508,
UMG509, UMG511, UMG512 or UMG96 RM-E mas-
ter devices and the respective PRO devices.
NOTE
The GridVis
®
Collector does not read the UMG 96RM-
CBM via the USB port! The UMG 96RM-CBM is read
out via the RS-485 interface!
2. 3 Initial commissioning
The initial commissioning is carried out according to the
following scheme:
· Installation of the GridVis plug-ins contained on the
supplied USB flash drive in the GridVis
®
software.
· Configuration of the IP addresses in the GridVis
®
software.
· Configuration of the measurement devices in the
GridVis
®
software.
· Save the initial configuration on the USB flash drive.
· Insert the USB flash drive into the GridVis
®
Collec-
tor. The GridVis
®
Collector recognizes the USB flash
drive and saves the configuration.
