Fig.:
Power supply,
display elements
and interfaces
Item Designation
1
Status LED
· Blue: Battery fully charged.
· Red:Battery is charging.
For additional LED statuses (operating modes), see section „4. 1 Location of connections and controls on the
GridVis® Collector“ on page 26.
2 Mini-USB charging port
3 USB 2.0 port
4 Ethernet interface
5 USB charging cable (USB to mini-USB connector)
6 Charger (power supply unit)
Table: Battery power supply
Battery charged
2
56
2
1
33
4
4
Battery charging
1
