13
UMG 604
PC
UMG
604
Ethernet
PC
UMG
604
RS232
RS485
PC
UMG
604
RS232
GridVis programming software
The UMG604 can be programmed and read
out using the GridVis
®
programming software
included in the scope of supply. This requires
a PC to be connected to the UMG604 via a
serial interface/ethernet.
GridVis features
• Programming the UMG604
• Configuring recordings
• Reading out recordings.
• Storing data in a database
• Graphic display of measured values
• Programming customer-specific applica-
tions.
Fig. 13.2 Connection of a UMG604 to a PC via
an interface converter.
Interface
converter
Fig.13.3 Connection of a UMG604 (with the
ethernet option) to a PC via the ethernet.
Fig. 13.1 Connection of a UMG604 to a PC via
an RS232 cable.
