UMG 604
Interfaces
RS232 : 5 pin screw-type terminals.
Protocol : Modbus RTU/slave
Transfer rate 9600 bps, 19.2 kbps, 38.4 kbps, 57.6 kbps ,
115.2 kbps
RS485 : 2 pin screw-type terminals.
Protocol, modbus RTU : Modbus RTU/slave, modbus RTU/master
Transfer rate : 9.6 kbps, 19.2 kbps, 38.4 kbps, 57.6 kbps,
115.2 kbps, 921.6 kbps
RS485 (optional) : Connector, SUB D 9 pin
Protocol, profibus (optional) : Profibus DP/V0 according to EN 50170
Transfer rate : 9.6 kbaud up to 12 Mbaud
Ethernet 10/100Base-TX (optional)
Connection : RJ-45
Functions : Modbus gateway, embedded web server (HTTP)
Protocols : TCP/IP, EMAIL (SMTP), DHCP-Client (BootP),
Modbus/TCP(Port 502), ICMP (Ping), NTP, TFTP,
Modbus RTU over Ethernet (Port 8000), FTP,
SNMP.
