janitza UMG 604 - Inputs and Outputs

65
UMG 604
Inputs and outputs
2 digital inputs
Pulse input (S0)
Maximum counting frequency : 20 Hz
Switching input
Response time (Jasic program) : 200 ms
Input signal applied : 18V. 28 V DC (typically 4 mA)
Input signal not applied : 0 .. 5 V DC, current less than 0.5 mA
2 digital outputs, semi-conductor relay, not short-circuit proof.
Switching voltage : max 60 V DC, 30 V AC
Switching current : max 50 mAeff AC/DC
Response time (Jasic program) : 200 ms
Output of voltage dips : 20 ms
Output of voltage overranges : 20 ms
Pulse output (operating pulses) : max 20 Hz
Cable length : up to 30 m unshielded
: greater than 30m shielded
Connectable conductors
Solid core, multi-core, flexible core : 0.08 - 1.5 mm
2
Pin-end connector, wire end ferrules : 1 mm
2
, only one conductor may connected per
terminal connection!
