janitza UMG 604 User Manual

7
UMG 604
Product No. Name
21 01 058 Battery, Lithium CR2032, 3V (according to UL 1642)
08 02 427 RS232, Connection cable (UMG 604 – PC), 2m, 5 poles
1)
Refer to delivery note for product number.
2)
Design version.
Scope of supply
Number Product No. Name
1 52 16 xxx
1)
UMG604 XX
2)
1 33 03 070 Operating manual and technical data
1 33.03.304 Quick guide (supplement to the operating instructions)
1 51 00 116 CD with the following content:
- “GridVis” programming software,
- Functional descriptions, GridVis, UMG604 ..
- GSD file “0B41.GSD” for profibus DP V0
1 10 01 807 Screw-type terminal, plug-in, 2 pin.
1 10 01 808 Screw-type terminal, plug-in, 3 pin.
1 10 01 809 Screw-type terminal, plug-in, 5 pin.
1 10 01 810 Screw-type terminal, plug-in, 6 pin.
1 89 10 051 Slot-head screwdriver (0.40x2 mm), ESD
1 08 01 505 Patch cable, 2m, twisted, grey. (UMG604 - PC/switch connection)
1 52 00 008 RS485 external terminating resistor, 120 ohm
Available accessories

janitza UMG 604 Specifications

General

Measurement Category	CAT III 600 V
Mounting Type	DIN Rail
Voltage Measurement	Yes
Current Measurement	Yes
Frequency Measurement Range	45-65 Hz
Power Measurement	Yes
Energy Measurement	Yes
Harmonics Analysis	Yes
Communication Interfaces	Yes
Display	LCD
Operating Temperature	-10 to +55 °C
Storage Temperature	-20 to +70 °C
Device Type	Power Analyzer
Harmonics	Up to 50th
Communication Interface	RS-485
Protocols	Modbus RTU
Accuracy Class	0.5S
