UMG 604
Recordings
2 recordings are preconfigured in the default
factory setting of the UMG604. Recordings
are adjusted and extended via the software
GridVis.
Recording 1
The following measured values are recorded
with the time base of 15 minutes:
• Voltage effective L1
• Voltage effective L2
• Voltage effective L3
• Voltage effective L4
• Voltage effective L2-L1
• Voltage effective L3-L2
• Voltage effective L1-L3
• Current effective L1
• Current effective L2
• Current effective L3
• Current effective L4
• Active Power L1
• Active Power L2
• Active Power L3
• Active Power L4
• Active Power Sum L1-L3
• Active Power Sum L1-L4
• Reactive power fundamental L1
• Reactive power fundamental L2
• Reactive power fundamental L3
• Reactive power fundamental L4
• Reactive power fundamental Sum L1-L3
• Reactive power fundamental Sum L1-L4
(The mean value, minimum value and
maximum value are also recorded for each
measured value.)
Recording 2
The following measured values are recorded
with the time base of 1 hour:
• Consumed Active Energy L1
• Consumed Active Energy L2
• Consumed Active Energy L3
• Consumed Active Energy L4
• Consumed Active Energy Sum L1-L3
• Consumed Active Energy Sum L1-L4
• Inductive Reactive Energy L1
• Inductive Reactive Energy L2
• Inductive Reactive Energy L3
• Inductive Reactive Energy L4
• Inductive Reactive Energy Sum L1-L3
• Inductive Reactive Energy Sum L1-L4
