Weight : 250g
Calorific value : 2,2MJ (610Wh)
Ambient conditions
Measurement category : III (Measurement within building installation)
Pollution degree : 2
Protection class : II = with protective earth
Ambient temperature : -10°C .. +55°C
Storage temperature : -25°C .. +70°C
Humidity : 15% up to 95% without dew
Protection class
Front : IP50 according to IEC60529
Front with seal (Option) : IP65 according to IEC60529
Back side : IP20 according to IEC60529
Mounting position : random
Operating height : 0 .. 2000m over sea level
Measurement
Measuring inputs
Measuring rate : 1 measurement per second
Rated pulse voltage : 4kV
Signal frequency : 45Hz .. 1000Hz
Scanning frequency : 2,5kHz/3,0kHz (Net frequency 50Hz/60Hz)
Measuring and operating voltage : see type plate
Fuse : 2A .. 10A (medium time lag type)
Frequency of fundamental : 45Hz .. 65Hz
Power consumption Phase (L-N) : ca. 0,1VA per phase.
230V/400V Standard version
operating voltage : 196 .. 255V AC
Range : L-N 50V .. 255V, L-L 86V .. 442V
120V/220V Special version
operating voltage : 90 .. 160V AC
Range : L-N 25V .. 160V, L-L 45V .. 277V
60V/120V Special version
operating voltage : 45 .. 80V AC
Range : L-N 16V .. 80V, L-L 28V .. 139V
Current measurement
Power consumption : approx. 0,2VA
Rated current at ../5A (../1A) : 5A (1A)
Minimum working current : 20mA
Current limit at ../1A : 1,2A (sinus shape)
Current limit at ../5A : 6A (sinus shape)
Overload : 150A for 2 Sec.
Accuracy class of energy measurement : class 2
Connectable cables
One wire, multiple-wire, fine wire : 0,08 - 2,5mm
2
Pin contacts : 1,5mm
2
, only one conductor may be connected
per terminal!
