janitza UMG96L User Manual

Page 26

Uncertainty of measurement
Quantity Indicating range Measuring range
1)
Measurement
uncertainly
2)
Auxiliary voltage
5)
196..255V
Voltage L-N 0 .. 34kV 50 .. 255V +-1,5% rng
Voltage L-L 0 .. 60kV 87 .. 442V +-2,0% rng
Current 0,00 .. 9,99kA 0,02 .. 6,00A +-1,0% rng
Current in N 0,00 .. 9,99kA 0,06 .. 18,00A +-3,0% rng
Real power, consumption, sum 0,00W .. 150MW 3,9W .. 3,825kW +-1,5% rng
Real power, supply, sum -0,00W .. -150MW -3,9W .. -3,825kW +-1,5% rng
Apparent power, sum 0,00VA .. 150MVA 3,9VA .. 3,825kVA +-1,5% rng
Reactive power (Q0), sum 0,00var .. 150Mvar 3,9var .. 3,825kvar +-1,5% rng
Auxiliary voltage
5)
90 .. 160V
Voltage L-N 0 .. 34kV 25 .. 160V +-1,5% rng
Voltage L-L 0 .. 60kV 45 .. 277V +-2,0% rng
Current 0,00 .. 9,99kA 0,02 .. 6,00A +-1,0% rng
Current in N 0,00 .. 9,99kA 0,06 .. 18,00A +-3,0% rng
Real power, consumption, sum 0,00W .. 150MW 1,8W .. 2,4kW +-1,5% rng
Real power, supply, sum -0,00W .. -150MW -1,8W .. -2,4kW +-1,5% rng
Apparent power, sum 0,00VA .. 150MVA 1,8VA .. 2,4kVA +-1,5% rng
Reactive power (Q0), sum 0,00var .. 150Mvar 1,8var .. 2,4kvar +-1,5% rng
Auxiliary voltage
5)
45 .. 80V
Voltage L-N 0 .. 34kV 16 .. 80V +-1,5% rng
Voltage L-L 0 .. 60kV 28 .. 139V +-2,0% rng
Current 0,00 .. 9,99kA 0,02 .. 6,00A +-1,0% rng
Current in N 0,00 .. 9,99kA 0,06 .. 18,00A +-3,0% rng
Real power, consumption, sum 0,00W .. 150MW 0,9W .. 1,2kW +-1,5% rng
Real power, supply, sum -0,00W .. -150MW -0,9W .. -1,2kW +-1,5% rng
Apparent power, sum 0,00VA .. 150MVA 0,9VA .. 1,2kVA +-1,5% rng
Reactive power (Q0), sum 0,00var .. 150Mvar 0,9var .. 1,2kvar +-1,5% rng
cos(phi) 0,00i .. 1.00 .. 0,00c
3)
Frequency (of voltage) 45,0 .. 65,0Hz +-1,5% rdg
Reactive energy, inductive
v
6)
< 10 0..999 999 9.99kvarh class 2
4)
v
6)
< 100 0..999 999 99.9kvarh class 2
4)
v
6)
>= 100 0..999 999 999kvarh class 2
4)
Real energy, consumption
v
6)
< 10 0..999 999 9.99kWh class 2
4)
v
6)
< 100 0..999 999 99.9kWh class 2
4)
v
6)
>= 100 0..999 999 999kWh class 2
4)
Working hours counter 0..999 999 999h +-2Min./Day
Attention!
The program allows current and voltage transformer ratio setting only, if the maximum phase
power can reach up to 50.0MW and the sum power can reach a maximum value of
150.0MW.
