Janome 1110DX User Manual

32
e
w
q
(A)
r
t
i
o
u
y
Two-Thread Serging
* In case of two-thread serging, use one needle thread and the lower looper thread. Remove other threads.
To attach the spreader
Put the tip of the spreader into the hole on the upper
looper, and slide the spreader down into the holder.
q Spreader
w Upper looper
e Holder
To remove the spreader
Pull tab A on the holder toward you lightly. Push the
bottom of the spreader up and pull it out.
For standard two-thread serging, set the machine as
illustrated.
r Lower looper pre-tension setting silder
(STD. position)
t Changeable thread guide (lower position)
Standard two-thread serging is as illustrated.
y Wrong side of fabric
u Needle thread
i Right side of fabric
o Lower looper thread

Janome 1110DX Specifications

General

Type	Mechanical
Stitch Count	14
Max Stitch Length	4 mm
Max Stitch Width	7 mm
Stitch Length	1 - 4 mm
Free Arm	Yes
Stitch Types	Flatlock
Presser Feet	Blind hem foot
Dimensions	30 x 25 x 30 cm
Speed	1300 stitches/minute
