Janome 1110DX User Manual

46
• Threading the Right Needle
Place the spool of thread on the front left spool pin.
*
The points to thread for needle on the right are
marked in blue.
*
A convenient threading chart is placed on the
machine body inside the looper cover.
1. Draw the thread through the thread guide second
from the left from back to front: (A)
1 Thread guide
2. Pass the thread through the holes in the second
row from the left of the thread guide plate as
illustrated.
2 Thread guide plate
1
2
2
1
1
2
3
5
4
67
8
9
10

Janome 1110DX Specifications

General

Type	Mechanical
Stitch Count	14
Max Stitch Length	4 mm
Max Stitch Width	7 mm
Stitch Length	1 - 4 mm
Free Arm	Yes
Stitch Types	Flatlock
Presser Feet	Blind hem foot
Dimensions	30 x 25 x 30 cm
Speed	1300 stitches/minute
