Janome 1110DX User Manual

50
• Threading the Left Needle
Place the spool of thread on the rear left spool pin.
*
The points to thread for needle on the left are
marked in orange.
*
A convenient threading chart is placed on the
machine body inside the looper cover.
1. Draw the thread through the thread guide on the
left from back to front.
1 Thread guide
1
2
2
1
2
3
4
6
9
8
7
2. Pass the thread through the holes on the left of
thread guide plate as illustrated.
2 Thread guide plate
5
1

Janome 1110DX Specifications

General

Type	Mechanical
Stitch Count	14
Max Stitch Length	4 mm
Max Stitch Width	7 mm
Stitch Length	1 - 4 mm
Free Arm	Yes
Stitch Types	Flatlock
Presser Feet	Blind hem foot
Dimensions	30 x 25 x 30 cm
Speed	1300 stitches/minute
