Dropping or Raising the Feed Dog
The drop feed lever is located underneath the free arm
bed on the back of the machine.
To drop the feed dog, push the lever in the direction of
the arrow q.
To raise the feed dog, push the lever in the direction
of the arrow w, as illustrated, and turn the handwheel
toward you.
The feed dog must be up for normal sewing.
NOTE:
Set the stitch length value at the minimum when lowering
the feed dog.
View from the rear
q
w
q
w
