14
Winding the bobbin
NOTE:
Set the speed control slider at its fastest position for
bobbin winding.
z Draw the thread from the spool and pass the thread
around the bobbin winding tension disk.
q Bobbin winding tension disk
x Put the bobbin on the bobbin winder spindle.
w Bobbin
e Bobbin winder spindle
c Hold the thread with both hands and wind it around
the bobbin clockwise several times.
v Insert the thread into one of the 3 slits of the flange
plate and pull the thread to cut.
r Flange plate
t Slit
b Push the bobbin to the right. The bobbin icon appears
on the LCD display.
y Bobbin icon
n Start the machine. When the bobbin is fully wound, it
will stop spinning automatically.
Stop the machine and return the bobbin winder to its
original position by moving the spindle to the left.
m Remove the bobbin. Insert the thread into the slit and
pull it to cut as shown.
q
w
e
r
t
y
q
w
e
r
z
x
c
v
b
n
m
