14
Setting the Spool of Thread
Horizontal spool pin
Lift up the spool pin. Place a spool of thread on the spool
pin.
Attach the large spool holder, and press it rmly against
the spool of thread so that the spool rests on the
supporter.
q Spool pin
w Spool of thread
e Large spool holder
r Supporter
The small spool holder is used with narrow or small
spools of thread.
t Small spool holder
e
Bobbin Winding
Removing the bobbin
Gently slide the hook cover release button to the right
and remove the hook cover plate.
Lift out the bobbin.
q Hook cover release button
w Hook cover plate
e Bobbin
q
w
e
r
t
y
u
i
Extra spool pin
The extra spool pin is for winding bobbins without
unthreading the machine.
Insert the extra spool pin into the hole.
The extra spool pin should point to the bobbin winder
tension disk.
Draw the thread from the spool and pass the thread
around the bobbin winding tension disk as shown.
y Extra spool pin
u Hole for extra spool pin
i Bobbin winder tension disk
w
q
NOTE:
Use the “J” plastic bobbins for horizontal hook (marked
with “J” r). Using other bobbins, such as pre-wound
paper bobbins, may cause stitching problems and/ or
damage to the bobbin holder.
r
