Page 47
3
4
1
2
Figure 8
Figure 9
3. Thread the Bobbin Winder as shown in Figure 8 by
feeding the thread through the loop (1) at the top of
the thread mast and then into the thread guide (2)
between the mast and the thread tensioner (3). Guide
the thread into the tensioner making sure to floss the
thread firmly between the discs. Then wrap it around
the bobbin in a clockwise direction (4) (Figure 8).
The thread guide works best when positioned at the
bottom of the thread mast, angled to the left toward
the bobbin area. If the thread comes out of the
tensioner discs during winding, loosen the set screw
in the thread guide collar and reposition the thread
guide to the left (toward the bobbin spindle). After it
is in position, tighten the set screw.
4. Use the speed selector knob to select the winding
speed. Hold the thread end and press the green
button to start winding the bobbin. If the thread
does not catch, press the red stop button, rewrap the
thread, and start winding the bobbin again.
If using a slotted bobbin, feed the end of the thread
from the inside of the bobbin to the outside through
the slot. Hold thread end as you begin to wind.
Optional Accessory
If using a spool of thread rather than a thread cone, use
an optional horizontal spool pin (available from Janome
Dealers) attached to the thead post (Figure 9). See your
Janome Dealer to order.
