Quilt Maker Pro 18 User Manual
201704
14. Ruler Foot
15. Needle
16. Needle Bar Thread Guide
17. Needle Bar
18. Presser Bar
19. Feet Mount
20. Needle Plate
21. LED Light Ring
22. Front Handlebar Connector
23. Ruler Base Position Guides
24. Front Wheel Base
25. Wheels (4)
26. Back Casing/Frame
27. Rear Wheel Base
28. Horizontal Spool Pin Hole*
Janome Quilt Maker Pro 18 Components
Back Side View
29. Spool Pin 1
30. Magnets
31. Serial Port for Stitch Regulator
32. Rear Handle Bar Serial Port
33. Rear Threaded Handles
34. LED Modules
35. Power Cord Connector
36. On/Off Switches
37. Spool Pin 2
38. Bobbin Assembly
Rear and Front Views
Figure 2.1
Figure 2
27
26
25
24
23
28
18
19
14
15
16
17
20
22
21
Front
35
29
30
38
Rear
34
31
32
33
35
36
37
* Horizontal Spool Pin is an optional accessory. Please contact your local Janome dealer to purchase.
