Jay electronique UC Series User Manual

UD - 319472K - 95 -FRENDE
Housing
ABS Choc, yellow - IP65 - Mechanical button protection
"6+2 button version" : 400 g
"8+2 button version" : 450 g
"10+2 button version" : 490 g
Dimensions
"6+2 button version" : 232x82x64 mm
"8+2 button version" : 251x82x64 mm
"10+2 button version" : 288x82x64 mm
Operating temperature range
- 20°C to + 50°C
Storage temperature range
without battery pack
- 30°C to +70°C
with battery pack
- 30°C to +35°C
Attachment when idle
Wall or belt by fastening strap
Power supply
Plug-in NiMH battery
In 433-434MHz bands : 24hours / 50% transmit time
In 869MHz band : 20hours / 50% transmit time
In 911-918MHz bands : 20hours / 50% transmit time
64 programmable frequencies in UHF 433-434 MHz bands
or 12 programmable frequencies in UHF 869 MHz band
or 64 programmable frequencies in UHF 911-918 MHz bands
<10 mW (license not required) in 433-434MHz or 869MHz
<94 dBµV/m in 911-918MHz
Modulation
FM
Average range (1) 100m in typical industrial environment
300m in unobstructed area
Function button type
6, 8 and 10 function buttons
- single speed pushbutton (1 step)
"BPSV"
- double speed pushbutton (2 steps)
"BPDV"
- rotary switch with 2 fixed positions
"COM2"
- rotary switch with 3 fixed positions
"COM3"
- rotary switch with 3 positions with auto. return "COM3R"
- electronic switch with 3 fixed positions
"BPTR"
- 1 pushbutton "On/Horn"
- 1 active priority emergency stop palmswitch
"Dead man" function
(Automatic shutdown of UDE transmitter)
Time is user-programmable
Indicator lights
1 red "battery level" and "diagnostic" indicator light
1 green "On" and "diagnostic" indicator light
Functionnal characteristics
Transmit radio frequency
(see list in appendix)
Endurance (25°C) with buttons typical
average use
Mechanical and environment withstand characteristics
Electrical and radio characteristics
Weight
(with battery pack)
Transmit power
(built-in antenna)
5.4-
UDEUDE
UDEUDE
UDE transmitter technical characteristics
5.4.1- Identity code
UDE transmitter and UDR receiver are linked by an identity code.
A receiver can only recognise and execute commands generated by the associated transmitter
(with electronic key containing the receiver identity code).
- The receiver identity code is a unique, fixed code (it can't be reprogrammed).
This identity code is contained in the electronic key and can be copied to a transmitter by a
trained and authorized user (see procedure in § 3.5.4)
Identity codes have 65536 different combinations.
(1) = Range will vary according to environment conditions of transmitter and reception antenna
(metal frameworks, walls … ).
