Jay electronique UC Series User Manual

- 98 - UD - 319472KFR EN DE
Housing
ABS, Grey - IP65
Weight
2 kg (approx.)
Dimensions
160x250x120 mm (without antenna and cable gland)
Operating temperature range
- 20°C to + 50°C
Storage temperature range
- 30°C to + 70°C
Cable lead-outs
Power supply : 1 M16 caps (Ø 5 to 7 mm cables)
UDF
module wiring : 3 M16 caps (Ø 5 to 7 mm cables) (1)
Control outputs : 1 M32 plastic cable gland (Ø 20 to 26 mm cables )
Connection
Spring-type terminal strips for 0.08² to 2.5² section wires
64 programmable UHF channels in 433-434 MHz bands
or 12 programmable UHF channels in 869 MHz band
or 64 programmable UHF channels in 911-918 MHz bands
ref:
VUB084,
1/4 wave for 433-434MHz bands
ref:
VUB086
, 1/2 wave for 869MHz band
ref:
VUB984
, 1/2 wave for 911-918MHz bands
Sensitivity
< -100dBm
DC version :
12VDC, 0 to +25%, 675mA and 188mA when idle
24VDC, -15% to +20%, 675mA and 188mA when idle
AC version n°1 :
24VAC, -15% to +10%, 850mA
48VAC, -15% to +10%, 400mA
AC version n°2
115VAC, -15% to +10%, 180mA
230VAC, -15% to +10%, 85mA
Control
1 "Horn" relay and 6,12 or 18 function relays
Safety
2 safety relays with linked and guided contacts
Response time
On start-up : 0,5s max.
On control : 55 ms max.
Active shutdown time
145 ms max.
Passive shutdown time
1,1 s max.
Indicator lights
1 red indicator light "power on"
1 red + 1 green indicator lights for diagnostic
1 red indicator light for relay status
Protections
Power supply :
Against polarity inversions for DC versions
Against overcurrents by fuse
Reception frequency
(see list in appendix)
Power supply and consumption
(2)
(with 2 safety relays and 8 control
relays pulled in, and 3 UDF
modules connected to receiver)
Mechanical and environment withstand characteristics
Radio characteristics
Electrical characteristics
Characteristics complying with ETS 300 220
Antenna
(BNC plug-in type)
(1) = UDF infrared modules are delivered with 1 M16 plastic cable gland
(2) = The number of function relays controlled simultaneously is limited to 10 relays with 1 UDF
module connected to UDR receiver, or to 9 relays with 2 UDF modules connected, or to 8 relays
with 3 UDF modules connected.
5.5-
UDR UDR
UDR UDR
UDR receiver technical characteristics
A large label in the housing cover gives the following information to facilitate configuration and
maintenance of the UD system :
- connection point numbers
- wiring indication
- fuse characteristics
- indicator light functions
- table showing the "Buttons/Relays/Functions" configurations for the application and the
interlocking configuration.
