JBI Alpha-Doc Mk4 - Tab Option Functionality

Section 6 Page
6. Options
ALPHAM4/V1 SEPT 2011
2
6.2 Tab Option
SIDE LAY GAUGE FOR TABS WITH THREE SOLENOIDS FOR ALPHA-DOC MK4
TECHNICAL SPECIFICATIONS
SHEET SIZE
A4 P
US P
297 x 210 mm
279.4 x 215.9 mm
FEASIBILITY ONLY ON
ROUND CORNERING TWO SIDES
MAXIMUM HEIGHT OF
TABS
13.5 mm
MINIMUM NUMBER OF
TABS
4
MINIMUM SIZE
of the margin from the edge
of the sheet
0 mm
UNFEASIBILITY
ROUND CORNERING ONE SIDE
SIZE OF SHEETS
Sheets between each index card
must have the same sizes as the
basis of the tab (size X) and the
same length (dimension Y) with a
0.2mm bracket.
ADVANTAGES
The second solenoid has to be located in the middle of the sheet to balance the lay gauge.
The lay gauge with three solenoids is made posible by the low pressure of the solenoids,
which enables the sheets not to be damaged.
EXAMPLES
1
st
sheet 2
nd
sheet 3
rd
sheet 4
th
sheet
Two solenoids must always be in jogging operation to ensure the pushing of
sheets.
Assembly : Remove the square of side lay gauge to replace by the Tab Option by using a
6-face key to remove the two screws. Connect the two electric wires on the tittle terminal
located on the support.
CAUTION
Disconnect the machine before operation.
Hmax.
X
Y
1
2
3
