JBI Alpha-Doc Mk4 - Troubleshooting: During Cycle

Section 7 Page
7. Troubleshooting
ALPHAM4/V1 SEPT 2011
2
7.2 Troubleshooting during cycle
7.2.1 Jamming
During cycle, three types of jamming can occur and stop the machine
cycling. After the machine stops, the screen displays one message indicating
the type of jamming detected.
Remove paper jammed and press on the F1 key to erase the jamming
message.
Message: «Entry jamming» or «Exit jamming»
To remove sheets under the punching unit :
- Open the perspex cover
- Maintain the upper belt support in high position with one hand
- Pull out the paper with the other hand
NOTICE
If offcut paper remains jammed, close the perspex cover and get
the tool into high position (see Section 5.5), then remove the
sheets.
Message: «Reception jamming»
To remove or replace sheets jammed in reception :
- Proceed as indicated on Section 5.9 to activate the lowering of the
reception unit and gain access to sheets.
7.2.2 Four other messages can be displayed :
Message:
«Emergency stop»
See Section 4
Message
: «Cover opened»
See Section 3.
Message: «Confetti tray full»
This message displays if :
- the confetti tray is full ⇒ empty the confetti tray
- the sensor and/or the reflector are ⇒ clean the sensor and
dirty the reflector
Message: «Tool overload»
This message displays if :
- Paper is jammed under the tool
- There is an hard point on the tool or the tool is not fitted well
- Tool driving is hard
- There is an electric fault : F4 fuse blown or trouble on the inverter
or the motor.
