jcb JCB-SCMS210 - Technical Data; Noise Information; Vibration Information

Voltage 230 – 240V ~50Hz
Power input 1400W
No load speed 4500 (min-1)
Blade diameter 210mm
Mitre angle adjustment 0 – 45
0
(right and left hand)
Bevel angle adjustment 0 – 45
0
(left hand only)
Wood (0
0
bevel angle) 240mm x 60mm
Wood (45
0
bevel angle) 240mm x 35mm
Protection class /2
Machine weight
14.05kg
NOISE INFORMATION
A weighted sound pressure LpA : 94dB(A)
A weighted sound power LwA : 107dB(A)
KpA & KwA = 3.0dB(A)
Wear ear protection when sound pressure is over: 80dB(A)
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined according to EN 60745:
Typical weighted vibrationt Vibration emission value ah = 3.384m/s
2
Uncertainty K = 1.5m/s
2
TECHNICAL DATA
