JessEm Mite-R-Excel II User Manual

Push the Fence Mount (Part #44) against the Gauge Body (Part #6) and retighten the (4)
four
#10-32 x 7/8"
Socket Head Screw (Part #9.3 & 9.4), you loosened in step "c" as shown in Figure
1
3
.
d.
Make sure the (2) ¼-28 x 5/16” Flat Point Set
Screw (Part # 39) are loose before moving on to
step (d). Set screws should not contact gauge
(Part #6) Shown in Figure 12
c.
39
Figure 12
Figure 11
9.3
9.4
9.3
9.4
b.
Loosen off (4) Four #10-32 x 7/8” Socket
Head Screw on both sides of the gauge (Part
#9.3 &
9.4) as shown in Figure 11.
11
44
9.3
6
9
.
4
39
Figure 13
6
