Jet ProShop II User Manual

9
5.0 Specifications
Table 1
Model number
JPS-10TSL
JPS-10TSL
Stock number
725000K-RU
725000K-3RU
Motor and Electricals
Motor type
Totally enclosed, fan cooled, induction
Horsepower
1.5Kw (2HP)
1.87kW (2.5HP)
Motor phase
1 PH
3Ph
Motor voltage
230 V
400 V
Cycle
50Hz
Listed FLA (full load amps)
11 A
4 A
Motor speed
2800 RPM
Starting amps
43.6
11.8
Running amps (no load)
7.3
1.5
Start capacitor
400MFD/125VAC
N/A
Run capacitor
50µF/350VAC
N/A
Power transfer
belt
On/off switch
Magnetic switch
KJD17B_230V (NVR type)
Magnetic switch
KJD18_400V (NVR type)
Power cord
H05VV-F x 3C 1.5mm²
H05VV-F x 4C 1.0mm²
Sound emission without load
2
80 dB at 30 in. (762mm) from blade
Arbor and blade
Arbor diameter
5/8” , flange with M30mm collar
Arbor speed
4000 RPM
Arbor lock
Included
Arbor wrench
Included
Blade included
10 in. (254 mm), 40 tooth
Maximum depth of cut at 90 degrees
3-1/8 in. (79 mm)
Maximum depth of cut at 45 degrees
2-1/8 in. (54 mm)
Maximum rip to right of blade
30 in. or 52 in.
Maximum rip to left of blade
13.5 in. (343 mm)
Blade height per one revolution of handwheel
5/32 in. (4 mm) at 90°; 7/64 in. (2.83 mm) at 45°
Dado maximum width
13/16 in. (20.6 mm)
Dado maximum diameter
8 in.
Blade tilt
45° left tilt
Table
Main table dimensions, L x W
20 x 27 in. (508 x 686 mm)
Table dimensions with wings, L x W
44 x 27 in. (1118 x 686 mm)
Table area in front of blade at maximum height
8.81 in. (223.83 mm)
Table height from floor, approximate
34-3/4 in. (883 mm)
Miter T-slot, W x D
3/4 x 3/8 in. (19 x 10 mm)
Edge bevel
Front
Main materials
Main table
Cast iron
Table insert
Aluminum
Extension wings
Cast iron
Base and legs
Steel
Center trunnion
Cast iron
Pulleys
Steel
