JetCat RX Series User Manual

PAGE 42 of 54
The INFO Menu
Info menu displays the following information:
Value
Explanation
Rest Fuel
Remaining fuel in tank. Tank size can be entered using the LIMITs menu. Value
is reset every time the ECU is switched on (or can be reset manually by pressing
the Change Value/Item button on the GSU).
Fuel Flow ml/min
Actual fuel consumption in ml/min.
BattCnd
Ubattery
The condition of the battery is indicated in the upper line:
1. --OK--
2. !WEAK!
3. --EMPTY--
1. If the battery voltage is 1.1V/Cell or higher “—OK--“ will be displayed.
2. If the battery voltage drops under 1.1V/Cell, the display will read “!WEAK!”.
Red Standby/Manual and green OK LED’s will blink simultaneously (at a
rate of twice per second). Starting the turbine is not possible, until the battery
is recharged. If the turbine is already running and the battery warning
function is enabled, the warning function will be activated.
3. If the battery voltage drops under 1.0V/Cell “—EMPTY--” is displayed.
Starting the turbine is not possible until the battery is recharged. If the
turbine is running, it will be immediately shut off, to avoid a malfunction of the
ECU.
Current voltage of the battery. Displayed on bottom line.
Baro
Temp
Indicate the current barometric pressure.
Temperature indicator (C°) in range of ECU
L-MinFuelQ
L-OffFuelQ
Minimum fuel quality during the last turbine run
Fuel quality by shut off at the last turbine run
L-BubblCnt
L-Bubble Tim
Number of bubbles counted during the last turbine run
Timefram in seconds of the bubble count during the last turbine run
Last Run Time
Last turbine run time.
Last Fuel Count
Quantity of fuel consumed, during the last turbine run.
Last-Off PmpVolt
Volts applied to the pump when it was switched off.
Last Off RPM
RPM of the turbine, when it was switched off.
Last Off TEMP
Temperature of the turbine, when it was switched off.
Last Off Cond
Last stored Off condition.
Last Max Temp
Maximum temperature during the last turbine run
Last Min Temp
Minimum temperature during the last turbine run
Last AVG Temp
Average temperature during the last turbine run
Last MaxR AVGTmp
Average full throttle temperature during the last turbine run
Last Max Pump
Maximum pump voltage during the last turbine run
Last Min Pump
Minimum pump voltage during the last turbine run
Last Avg Pump
Average pump voltage during the last turbine run
Last Fail Safe Cnt
Number of Fail Safe during the last turbine run
Last Fail Safe Time
Fail Safe Time in seconds
Last-Max AirSpd
Maximum reached flight speed during the last flight
(Only by connected Airspeed sensor!)
Last AvgAirSpd
Average flight speed during the last flight
(Only by connected Airspeed sensor!)
Last Distance
Flight distance traveled during the last flight
(Only by connected Airspeed sensor!)

JetCat RX Series Specifications

General

Type	Turbine
Thrust	22 - 240 N
Thrust Range	22 - 240 N
Weight	0.5 - 3.5 kg
Diameter	80 - 150 mm
Fuel	Kerosene
Lubrication	5% Turbine Oil mixed with Fuel
Starter	Electric
