PAGE 53 of 54
Special Function
Temperatur adjustment
After a replace of a temperature sensor it need be necessary to run a temperature
calibration
How to manage:
The turbine must be at ambient temperature (ca. 21°C) !!!
Press and hold the „Select Menu“ key on GSU, then swictch on ECU (receiver).
Instead of „Select Menu“ key of GSU, it’s possible to press the little key on the LED-
board.
The LED´s indicate the following blink sequence :
LED Blink Sequenz
Standby (yellow)
Pump running (red)
OK (green)
The dispaly of GSU indicate simultanously :
Release Key to „Learn RC“
While this sequence hold the key „SelectMenu“don’t realease it !!!!
Release the key if the three LED´s indicate this blink sequence:
LED Blink Sequenz
Standby (yellow)
Pump running (red)
OK .... (green)
The Display of the GSU indicate simultanously:
“Release Key to Calibrate Temp“
after releasing the key on the GSU the temperature calibration runs.
