PAGE 40 of 54
Menu Structure
All similar data and running parameters are grouped in separate menus. Menus can be displayed and their
values modified (where accessible), by using the GSU.
Menu Selections
RUN menu
MIN/MAX menu
RC-Check menu
INFO menu
STATISTICS menu
LIMITS menu
TEST menu
Selecting a Menu
The corresponding buttons (hot keys) can directly select the “Run”, “Info”, “MIN/MAX”, or “Limits” menus.
An alternate method is to press and hold the Select Menu button and use the + / - buttons for selecting.
Note: this method is the only access to all menus.
Change Values / Items
In order to change an indicated value, press and hold the Change Value/Item button while using the + / -
buttons to alter its value. An arrow () will appear in front of the value, if it can be changed.
The RUN Menu
As soon as the ECU is switched on, the Run menu is displayed.
In the lower display line, the actual turbine RPM is indicated.
In the upper display line, the following selections can be monitored. Use the + / - buttons alone for
selecting the different parameters.
Current EGT (Exhaust Gas Temperature).
The units, °C or °F can be selected in the LIMITs menu.
Last Off command (reason for shut down). See table on page 28
Current Air speed (km/h) this readout is usual for function check of the speed sensor.
Note : This readout is only supported by connected airspeed sensor.
Target state-air speed (km/h). This readout is for checking at the “speed control” mode
the set target state-airspeed of throttle stick.
Note: This readout is only supported by connected airspeed sensor.
