JetCat RX Series User Manual

PAGE 41 of 54
The Min/Max Menu
The Min/Max menu is used primarily for diagnostics purposes. All of the following variables may be
sampled manually by pressing the Change Value/Item button on the GSU.
Value
Explanation
Upump-Max
Upump-Min
Maximum pump voltage.
Minimum pump voltage.
MaxTemp
MinTemp
Maximum EGT.
Minimum EGT.
MaxRpm
MinRpm
Maximum turbine RPM.
Minimum turbine RPM.
MaxAirSpd
AvgAirSpd
Maximum Airspeed (*)
Average Airspeed (*)
Flight Distance
Flight distance in km (*)
AvgRpm
MaxRTmp
Average-RPM
Average temperature at full throttle
AvgPump
AvgTemp
Average pump voltage
Average temperature
(*) Only by connected air speed sensor!
The Min/Max values can be reset by pressing “Change Value”key.
The values are only valid during and after the actual run. By switching on the ECU they
are reset
The R/C Check Menu
All parameters in this menu are for informational purposes only and will vary in accordance with R/C input.
Value
Explanation
Throttle%
StickPulse
Position of the throttle stick (by percentage, 0-100%).
Position units of the throttle stick.
AuxInp%
AuxPulse
Position of the 3-position AUX channel (by percentage, 0-100%).
Position units of the AUX channel.
Aux.Position
Position of the AUX channel control
(0=Off; 1=Start/Standby; 2= AutoOff).
Fail Safe Count
F
Indicate the numbers of Fail Safes since the ECU is active
Fail Safe Time
In seconds
Indicate Fail Safe-time (sec.) the ECU recognized since it is active
Menu parameters are for informational purposes only and cannot be changed.

JetCat RX Series Specifications

General

Type	Turbine
Thrust	22 - 240 N
Thrust Range	22 - 240 N
Weight	0.5 - 3.5 kg
Diameter	80 - 150 mm
Fuel	Kerosene
Lubrication	5% Turbine Oil mixed with Fuel
Starter	Electric
